The RS8200 is a 20 tonne mechanical soil compactor. The Weichai Deutz engine combined with well proven SDLG technologies provides a reliable machine. The RS8200 offers dual vibration frequencies that are adjustable from inside the cab and uses a fixed shaft power shift transmission to ensure excellent compaction results.
| Specifications | |
|---|---|
| Approach angle back | 29 Deg |
| Articulation either side | 35 Deg |
| Centrifugal force high / low amp | 360 / 280 kN |
| Drum width | 2 150 mm |
| Engine Make | Weichai Deutz |
| Engine Model | WP6G175E201 |
| Fuel tank capacity | 220 L |
| Gradeability without vibration | 30% |
| Machine width | 2 320 mm |
| Net power | 129 Kw @ 2 000 rpm |
| Nominal amplitude | 2.0 / 1.0 |
| Operating weight | 20 000 kg |
| Overall height | 3 185 mm |
| Overall length | 6 370 mm |
| Static weight on drum | 10 000 kg |
| Transmission type | Fixed shaft power shift |
| Turning radius | 6 600 mm |
| Type | Single drum compactor |
| Vibration frequency | 28 / 35 Hz |
