SDLG RD7140 Double-drum Hydraulic Articulation Road Roller
Engine:
Engine Model:Deutz BF4M2012 (EC Stage III&EPA Tier III)
Rated power:98KW/2300r/min.
Type:Inline,water cooling,4-stroke,direct injectioin.
Overall size:
Dimension(LXWXH)mm:5100x2300x3050mm.
Vibration wheel width/Diameter,mm:2130mm
Compacting width,mm:2130mm
Min.Turning Raduis,mm:6500mm.
Parameter:
Operation weight:14000KG.
Nominal vibration amplitude:0.82/0.33mm
Vibration frequency: 45/66.7Hz
Vibration force: 186/163kN
Transmission:
Gear shift: forward 2/reverse 2.
Speed :forward/reverse I 0~9km/h ,forward/reverse II 0~13.5km/h
